SELFOC® Lens Array (SLA)

Applications

  • Copier
  • Facsimile
  • CRT Printer
  • LED/LCD Printer
  • Electronic Copyboard
  • Scanner
  • Hand-held copier
  • Card Reader

Lens ArrayThe SELFOC Lens Array is used in 1:1 image transfer applications. The arrays are composed of one or more rows of lenses. The images from adjacent lenses overlap and form a continuous erect image. The SLA's short total conjugate (TC), ranging from 9 to 80 mm, allows the designer to decrease the optical path length and, thus, reduce the overall size of the system.
